Ecology will track rocks’ movements along coast to see if anti-erosion efforts are working

Using tracking devices to follow the movement of rocks may seem odd, but that’s what’s being done to help the state Department of Ecology and Grays Harbor residents track the effectiveness of anti-erosion measures on the shoreline at North Cove, also known as Washaway Beach.

North Cove community members teamed last week with the Department of Ecology to drill holes in about 140 rocks and fit them with passive-integrated transponders, also known as PIT tags. These will be placed among the rock cobble that makes up what is known as the dynamic revetment – strategically placed cobble stones designed to disperse wave energy and limit shoreline erosion. The stones will be monitored to follow their movement along the coastline.

“It was great to see the high level of enthusiasm and participation of the local community,” said George Kaminsky, Department of Ecology coastal engineer, who has been monitoring the rapid erosion of the North Cove shoreline for 25 years. “Their support of this research is incredible, and it is wonderful to experience the positive spirit of the North Cove community.”

Local resident Connie Allen, one of the driving forces behind North Cove’s “Wash Away No More” movement to control shoreline erosion, described the day’s activities.

“Richard Harris, who hosted the rock-drilling event, gathered and washed local basalt weighing 3 to 40 pounds. We sorted the stock into three sizes and drilled the appropriate size hole. After cleaning and drying the hole, Diana McCandless secured the tracking device with silicone.”

Harris is among those that had property in the North Cove area that washed away.

Ecology measured, weighed, photographed and recorded the identification number of each of the rocks. The rocks were placed Friday “along the dynamic revetment at specific profile locations and elevations,” their placement carefully logged, said Kaminsky.

The tracking devices are small tubes that “work like the chip on a credit card,” Allen said.

“Each tag has a unique identification number that is detected with an antenna connected to a reader unit,” said Kaminsky. The antenna is an oval-shaped wire ring attached to handle and is used similar to a metal detector to locate tagged rocks. “Over time we will use the antenna and reader to detect the tagged cobbles and examine the distance and direction they are moved by waves and currents. We will learn how they may get sorted by size, and also how the size and shape of the cobbles change over time due to collision and abrasion with other rocks. This will help us determine the durability of the material, and how to optimize the overall performance at minimum cost.”

Kaminsky said there will be short-term monitoring this month and more surveys in February and March.

“Monitoring the change in size of the cobbles is more labor intensive and will be done less frequently, depending on how quickly they appear to be getting smaller, and the extent to which funding allows,” said Kaminsky.

Also on hand Wednesday was Paul Bayle, a coastline researcher from the University of Bath in southern England. He is researching dynamic revetment using lidar technology, which works similarly to radar but instead makes measurements useing laser lights.

“Little North Cove is of interest to English coastline research,” said Allen.

While the dynamic revetment so far appears to have proven effective along North Cove, Kaminsky said very little research has been done to understand exactly how it works.

“The dynamic revetment that backs a sand beach mimics the functions of a natural composite beach that has gravel and cobble generally above mean higher high water and sand below that elevation,” he said. “While these kinds of beaches exist in many places around the world, relatively little research has been done to understand how these two types of materials across the beach profile work together to reduce the erosive power of storms, and under more moderate conditions, how the gravel and cobble material absorbs the run-up of waves to build up the sand levels along the upper beach.”
